BTB-0517板对板 0.5mm 合高6

BTB-0517板对板 0.5mm 合高6

  • 产品特性
  • 应用范围

图纸下载 样品申请

BTB连接器技术指标:
额定电流3.0AMP
接触电阻20mΩ   Max
耐电压1000V   AC/DC
绝缘电阻1000mΩ   Min
工作温度﹣40℃   to   +105℃
接触材料 Brass
接触镀层 Au   Or Sn over Ni
绝缘材料 PA9T   Black+30%GF UL94V-0 BK
品牌 科斯达  KOSOD  KSDKG

BTB Connector Specifications:
 Rated current 3.0AMP
Contact resistance 20mΩ Max
Withstand voltage 1000V AC/DC
Insulation resistance 1000mΩ Min
Operating temperature -40℃ to +105℃
Contact material Brass
Contact Plating Au Or Sn over Ni
Insulation material PA9T Black+30%GF UL94V-0 BK
Brand KOSOD KOSOD   KSDKG
