电源开关技术参数
1、功能：OFF-ON2、评级：U:TV-5
ENEC VDE/cQc：8A/128A u 250V~T853、操作力：700士300g.f
4、接触电阻：≤ 50mn5、绝缘电阻：≥100 Mn
6、绝缘耐压：端子T0按钮3000VAC/5mA/1MINTUE
TERMINALTO TERMITNAL1500VAC/5mA/1MINTUE
Power switch technical parameters
1、FUNCTION:OFF-ON2、RATING:U:TV-5
ENEC VDE/cQc: 8A/128A u 250V~T853、OPERATION FORCE: 700士300g.f
4、CONTACT RESISTANCE:≤ 50mn5、INSUL.ATION RRSTSTANCE:≥100 Mn
6、DIELECTRIC WITHSTAND: TERMINAL T0 BUTTON 3000VAC/5mA/1MINTUE
TERMINALTO TERMITNAL1500VAC/5mA/1MINTUE
