线数：02 ~ 16P
接触电阻：≤20mΩ
绝缘电阻： ≥1000MΩ
额定电压：250V AC DC
额定电流：7.OA AC DC
耐 电 压： 1500V AC/minute
材 料：磷铜 LCP米色
温度范围：-25℃~+105℃
包装：2/3/4/500/袋 其他300/袋
品牌 科斯达 KOSOD KSDKG
Number of lines: 02 ~ 16P
Contact resistance: ≤20mΩ
Insulation resistance: ≥1000MΩ
Rated voltage: 250V AC DC
Rated current: 7.OA AC DC
Withstand voltage: 1500V AC/minute
Material: Phosphor Bronze LCP Beige
Temperature range: -25℃~+105℃
Packing: 2/3/4/500/bag, other 300/bag
Brand KOSOD KOSOD KSDKG
