WA-121

线 数：2-7
额定电流：1.5A
额定电压：50V
耐电压：500V
接触电阻：≤20mΩ
绝缘电阻：100MΩ
工作温度：-20℃~+85℃
塑件(材质)：6T, UL94V-0
插簧(材质)：黄铜，镀锡
焊片(材质)：磷青铜，镀锡
品牌 科斯达  KOSOD  KSDKG

Number of lines: 2-7
Rated current: 1.5A
Rated voltage: 50V
Withstand voltage: 500V
Contact resistance: ≤20mΩ
Insulation resistance: 100MΩ
Working temperature: -20℃~+85℃
Plastic parts (material): 6T, UL94V-0
Insert spring (material): brass, tin plated
Solder Tab (Material): Phosphor Bronze, Tin Plating
Brand KOSOD KOSOD KSDKG
