船型开关 技术参数
1.功能：关-开
2、额定值：UL 8(8)A 125/250VAC 25T125/555E4
TUV/CE/cQc：8/128A 250VAC T105
3
ENEC VDE(4A 250VAC T105/5512A 125VAC
4、
KC：10(4)A 250V~T105/55
5、工作力：650士350g.f
6.接触电阻≤50mn
绝缘电阻：100Mo
绝缘耐压：终端按钮 3000VAC/5mA/1MINTUE，
TERMINAL.TO TERMINAL150OVAc/5mA/1MINTUE
ROCKER SWITCH TECHNICAL PARAMETERS
1.FUNCTION:OFF-ON
2、RATING: UL 8(8)A 125/250VAC 25T125/555E4
TUV/CE/cQc: 8/128A 250VAC T105
3
ENEC VDE(4A 250VAC T105/5512A 125VAC
4、
KC: 10(4)A 250V~T105/55
5、PERATION FORCE:650士350g.f
6.cONTACT RESISTANCE ≤50mn
INSULATION RESISTANCE: 100Mo
DIELECTRIC WITHSTAND:TERMINALTO BUTTON 3000VAC/5mA/1MINTUE,
TERMINAL.TO TERMINAL150OVAc/5mA/1MINTUE
